Sun Fire[tm] V1280/Netra [tm]Server


Sun V1280

Processors |System Boards | Main Memory | Standard Interfaces | Internal Mass Storage | Power Supplies
Environment | Regulations | Dimensions and Weight | Clearance and Service Access | Racking

Processors
top

Number: 4, 8, or 12

Architecture: 900 or 1200 MHzUltraSPARC[tm] Cu (copper based) III

Cache per processor: Primary (L1): Parity protected 32 KB instruction and 64 KB data on chip (single-bit errors are corrected)
Secondary (L2): 8 MB external cache

System Interconnect: 9.6 GB/s Sun Fireplane interconnect.
System bus with redundant data, address and response crossbar interconnect

X4070A - Sun Fire 6800 Level 2 Repeater Board
System Boards
top

Number of boards : Maximum of 3 CPU/Memory boards

CPU/Memory board: Four processors each and up to 32 GB memory per board; maximum 12 processors per server.
X7057A - CPU/Memory board with 4 X 900 MHz /8MB Cache & 8GB
XCPU1280-442-1200 - CPU/Memory UniBoard w/ 4× US III Cu 1200MHz, 8GB
XCPU1280-482-1200 - CPU/Memory UniBoard w/ 4× US III Cu 1200MHz, 16GB
XCPU1280-484-1200 - CPU/Memory UniBoard w/ 4× US III Cu 1200MHz, 32GB
XE29BRD-482-1050 - CPU/Memory UniBoard w/ 4× US IV 1050MHz, 16GB
XE29BRD-482-1200 - CPU/Memory UniBoard w/ 4× US IV 1200MHz, 16GB
XCPU1280-482-1200 - CPU/Memory UniBoard w/ 4× US III Cu 1200MHz, 16GB
XE29BRD-482-1350 - CPU/Memory UniBoard w/ 4× US IV 1350MHz, 16GB
XE29BRD-484-1050 - CPU/Memory UniBoard w/ 4× US IV 1050MHz, 32GB
XE29BRD-484-1200 - CPU/Memory UniBoard w/ 4× US IV 1200MHz, 32GB
XE29BRD-484-1350 - CPU/Memory UniBoard w/ 4× US IV 1350MHz, 32GB
540-4979 - CPU/Memory UniBoard w/ 4× US III Cu 2.3 900MHz, 0MB
Tyco socket (-07 = Cinch socket)
540-5849 - CPU/Memory UniBoard w/ 4× US III Cu 1200MHz, 0MB
540-6038 - CPU/Memory UniBoard w/ 4× US IV 1200MHz, 0MB
540-6077 - CPU/Memory UniBoard w/ 4× US IV 1050MHz, 0MB
540-6442 - CPU/Memory UniBoard w/ 4× US IV+ 1500MHz, 0MB


Main Memory
top

8 GB to 96 GB (Using 1 GB DIMMS)
X7051A - 2GB Memory kit (4 x 512MB SDRAM DIMMs)
X7053A - 1GB Memory kit (4 x 256MB SDRAM DIMMs)
X7056A - 4GB Memory kit (4 x 1GB SDRAM DIMMs)
501-5030 - 2GB Memory kit (4 x 512MB SDRAM DIMMs)
501-5401 - 1GB Memory kit (4 x 256MB SDRAM DIMMs)
X7058A-Z - 8GB Memory Kit(4 X 2GB SDRAM DIMMs)
Standard Interfaces
top

Alarm: One alarm port (DB15)

Ethernet:

  • One ethernet/fast ethernet (10BASE-T/100BASE-T) twisted-pair port (RJ-45)
    (Used for LOM/System Controller)
  • Two 10/100/1000BASE-T Ethernet (copper) ports

X4150A - GigaSwift Ethernet UTP (GCS)
X4151A - GigaSwift Ethernet MMF (GFS)
X1034A - Quad FastEthernet PCI (QFE/P)
X1150A - Sun GigaSwift Ethernet UTP (Copper)
X1151A - Sun GigaSwift Ethernet MMF (Fiber)
X3150A - Sun GigaSwift Ethernet UTP (Copper)
X3151A - Sun GigaSwift Ethernet MMF (Fiber)
X4445A - Quad GigaSwift PCI-X Ethernet (QGE-X),
X5544A-4 - 10Gb PCI-X Ethernet Adapter, no transceiver
X5558A - XFP Optical Transceiver Multi Mode Fibre
X5559A - XFP Optical Transceiver Single Mode Fibre

PCI: Six open 7 in., 64 bit PCI slots:

  • One 66MHz
  • Five 33MHz

SG-XPCI1FC-EM4-Z - 4Gb PCI-X Single FC Host Adapter
SG-XPCI2FC-EM4-Z - 4Gb PCI-X Dual FC Host Adapter

Serial:

  • One RS-232/RS-423 asynchronous/synchronous serial port (RJ45), Serial A
  • Serial B is reserved.

SCSI: One Ultra3 SCSI 68-pin SCSI port

Single-ended (40MB/sec) or LVD (160MB/sec)

SGXPCI2SCSILM320-Z - PCI Dual Ultra320 SCSI Adapter
SG-XPCI2SCSI-LM320 - PCI/PCI-X Dual Ultra320 SCSI Adapter
X6541A - Dual Differential Ultra/Wide SCSI (UDWIS/P)(HVD)
X6758A - PCI Dual Ultra3 SCSI Host Adapter (LVD)
SG-XPCI1FC-EM2 - 2Gb PCI-X Single FC Host Adapter, RoHS:Y
SG-XPCI1FC-EM4-Z - 4Gb PCI-X Single FC Host Adapter, RoHS:Y
SG-XPCI1FC-QF4 - 4Gb PCI-X Single FC Host Adapter, RoHS:Y
SG-XPCI1FC-QL2 - 2Gb PCI-X Single FC Host Adapter, RoHS:Y
SG-XPCI2FC-EM2 - 2Gb PCI-X Dual FC Host Adapter, RoHS:Y
SG-XPCI2FC-EM4-Z - 4Gb PCI-X Dual FC Host Adapter, RoHS:Y
SG-XPCI2FC-QF2-Z - 2Gb PCI Dual FC Host Adapter, RoHS:Y
SG-XPCI2FC-QF4 - 4Gb PCI-X Dual FC Host Adapter, RoHS:Y
X6727A - PCI Dual FC Host Adapter+, RoHS:YL
X6767A - 2Gb PCI Single FC Host Adapter
X6768A - 2Gb PCI Dual FC Host Adapter
X6799A - PCI Single FC Host Adapter


Internal Mass Storage
top

Disks: Two 36GB SCSI internal disks, 1.0 in., 10,000 RPM

Sun Fire V1280 only:
Two 73GB SCSI internal disks, 1.0 in., 10,000 RPM
X5263A - 73.4GB Ultra SCSI 10000 RPM
X5268A - 146GB 10000 RPM 1" SCSI Disk

DVD-ROM: DVD-ROM internal drive
370-4412 - Slimline 8X DVD-ROM / 24X CD-ROM

Tape: DDS-4 tape drive (optional)
SG-XTAPDAT72-3F68 - 36-72GB 4 mm DAT 72 3.5-inch Tape Drive
X6297A - 20-40GB 4 mm DDS-4 DAT Tape Drive



SG-XMEDDAT72-10 - DAT 72 Data Cartridges, 10 pack
Power Supplies
top

Four power supplies providing 2N hot-pluggable redundancy; only two are required for the system to run

300-1833 - A209N 1500/1970 Watt AC Input Power Supply, RoHS:YL
300-1882 - A166 1500 Watt AC Input Power Supply, RoHS:YL
300-1884 - AC/DC Input DC Power Distribution Board, RoHS:YL

Enviornment
top

AC input (Sun Fire V1280): 200-240V single phase AC, 47-63Hz, with two 11/13 Amp circuits redundant with another two on a separate grid

DC input (Netra 1280): -48VDC or -60VDC

Input power: 3300W maximum

Heat Output: Base Configuration: 4,780 BTU/hr
Maximum Configuration: 11,300 BTU/hr

Temperature: Optimal: 22° C (72° F)
Range: 5° C to 40° C (41° F to 104° F)

Humidity: Optimal: 45% non-condensing
Range: 10% to 90% non-condensing humidity

Altitude: Up to 3,048 meters (10,000 ft)

Acoustic noise: 73 dB(A)


Regulations :(meets or exceeds the following requirements)
top

Safety: North America: UL 60950 3rd edition, CSA C22.2 No 60950-00 3rd edition (Certified: UL and UL for Canada)
European Community: EN 60950:2000, (Certified: UL for Germany/GS-Mark and GOST R for Russia)
Worldwide except North America: IEC 60950:1999 and CB Bulletin (Certified: DEMKO + UL for Argentina/IRAM S-Mark)

RFI/EMI: Class A: Australia/New Zealand AS/NZ 3548, Industry Canada ICES-003, European Community EN55022/CISPR22, Japan VCCI, Taiwan CNS 13438, and US FCC 47CFR15.B.

Immunity: EN55024, i.e. EN61000-4-2, EN61000-4-3, EN61000-4-4, EN61000-4-5, EN61000-4-6, EN61000-4-8, and EN61000-4-11

Dimensions and Weights
top

Height : Chassis Only: 20.75 in (527 mm) / 12U
With Cradle: 21 in (533.4 mm)

Width: Chassis Only: 16.75 in (425.6 mm)
With Baseline Skirt: 17.38 in (441.4 mm)
With Slides: 17.5 in (445 mm)

Depth: Chassis Only: 22 in (558 mm)
With Slides: 22.36 in (568 mm)

Weight: Chassis Only: 235.89 lbs (107 kg)
With Cradle: 286.60 lbs (130 kg)


Clearance and Service Access
top

Front: 3.5 in (88.9 mm)

Rear: 3.5 in (88.9 mm)


Racking
top 		All Sun racks and most third party; 24 in. (600mm) and deeper racks; 2 per 4 post rack, 1 per 2 post rack



A40 V1280 Server
